Paslanmaz Boru Çıkışlı S Tipi Düz Hortum Rakorları

Technical product passport

Stainless L Type Straight Welding Pipe Connectors

Stainless L Type Straight Welding Pipe Connectors

Product code: —
Product family: Stainless Steel Hose Connectors

Specify technical dimensions or quantity in the Turkish quote request.

Technical data

Technical dimensions 1

SERİ SERIE	HORTUM ÇAPI DN	HORTUM ÇAPI DN	D Boru D.Ç. Tube O.D.	KOD CODE	A	C	L
SERİ SERIE	INCH	MM	D Boru D.Ç. Tube O.D.	KOD CODE	A	C	L
BPHBC1	3/16"	5	6L	BPHBC10506	26,5	3	20
BPHBC1	3/16"	5	8L	BPHBC10508	28,5	3	22
BPHBC1	1/4"	6	6L	BPHBC10606	28,5	4	20
BPHBC1	1/4"	6	8L	BPHBC10608	31	4	22
BPHBC1	5/16"	8	8L	BPHBC10808	31	5	23
BPHBC1	5/16"	8	10L	BPHBC10810	31,5	5,5	23
BPHBC1	3/8"	10	10L	BPHBC11010	34	7	25
BPHBC1	3/8"	10	12L	BPHBC11012	34	7	25
BPHBC1	3/8"	10	15L	BPHBC11015	36,5	7	28
BPHBC1	1/2"	12	12L	BPHBC11212	34	9	25
BPHBC1	1/2"	12	15L	BPHBC11215	33	9,5	25
BPHBC1	1/2"	12	18L	BPHBC11218	32	9,5	27
BPHBC1	5/8"	16	18L	BPHBC11618	35,5	12,5	27
BPHBC1	5/8"	16	22L	BPHBC11622	36,5	12,5	27
BPHBC1	3/4"	19	22L	BPHBC11922	38	14,5	27
BPHBC1	1"	25	28L	BPHBC12528	41,5	20	30
BPHBC1	1 1/4"	31	35L	BPHBC13235	47	25,5	36
BPHBC1	1 1/2"	38	42L	BPHBC13842	47	31,5	36

SERİ SERIE: SERİ SERIE
HORTUM ÇAPI DN: INCH
HORTUM ÇAPI DN: MM
D Boru D.Ç. Tube O.D.: D Boru D.Ç. Tube O.D.
KOD CODE: KOD CODE
A: A
C: C
L: L

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 3/16"
HORTUM ÇAPI DN: 5
D Boru D.Ç. Tube O.D.: 6L
KOD CODE: BPHBC10506
A: 26,5
C: 3
L: 20

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 3/16"
HORTUM ÇAPI DN: 5
D Boru D.Ç. Tube O.D.: 8L
KOD CODE: BPHBC10508
A: 28,5
C: 3
L: 22

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1/4"
HORTUM ÇAPI DN: 6
D Boru D.Ç. Tube O.D.: 6L
KOD CODE: BPHBC10606
A: 28,5
C: 4
L: 20

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1/4"
HORTUM ÇAPI DN: 6
D Boru D.Ç. Tube O.D.: 8L
KOD CODE: BPHBC10608
A: 31
C: 4
L: 22

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 5/16"
HORTUM ÇAPI DN: 8
D Boru D.Ç. Tube O.D.: 8L
KOD CODE: BPHBC10808
A: 31
C: 5
L: 23

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 5/16"
HORTUM ÇAPI DN: 8
D Boru D.Ç. Tube O.D.: 10L
KOD CODE: BPHBC10810
A: 31,5
C: 5,5
L: 23

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 3/8"
HORTUM ÇAPI DN: 10
D Boru D.Ç. Tube O.D.: 10L
KOD CODE: BPHBC11010
A: 34
C: 7
L: 25

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 3/8"
HORTUM ÇAPI DN: 10
D Boru D.Ç. Tube O.D.: 12L
KOD CODE: BPHBC11012
A: 34
C: 7
L: 25

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 3/8"
HORTUM ÇAPI DN: 10
D Boru D.Ç. Tube O.D.: 15L
KOD CODE: BPHBC11015
A: 36,5
C: 7
L: 28

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1/2"
HORTUM ÇAPI DN: 12
D Boru D.Ç. Tube O.D.: 12L
KOD CODE: BPHBC11212
A: 34
C: 9
L: 25

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1/2"
HORTUM ÇAPI DN: 12
D Boru D.Ç. Tube O.D.: 15L
KOD CODE: BPHBC11215
A: 33
C: 9,5
L: 25

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1/2"
HORTUM ÇAPI DN: 12
D Boru D.Ç. Tube O.D.: 18L
KOD CODE: BPHBC11218
A: 32
C: 9,5
L: 27

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 5/8"
HORTUM ÇAPI DN: 16
D Boru D.Ç. Tube O.D.: 18L
KOD CODE: BPHBC11618
A: 35,5
C: 12,5
L: 27

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 5/8"
HORTUM ÇAPI DN: 16
D Boru D.Ç. Tube O.D.: 22L
KOD CODE: BPHBC11622
A: 36,5
C: 12,5
L: 27

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 3/4"
HORTUM ÇAPI DN: 19
D Boru D.Ç. Tube O.D.: 22L
KOD CODE: BPHBC11922
A: 38
C: 14,5
L: 27

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1"
HORTUM ÇAPI DN: 25
D Boru D.Ç. Tube O.D.: 28L
KOD CODE: BPHBC12528
A: 41,5
C: 20
L: 30

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1 1/4"
HORTUM ÇAPI DN: 31
D Boru D.Ç. Tube O.D.: 35L
KOD CODE: BPHBC13235
A: 47
C: 25,5
L: 36

SERİ SERIE: BPHBC1
HORTUM ÇAPI DN: 1 1/2"
HORTUM ÇAPI DN: 38
D Boru D.Ç. Tube O.D.: 42L
KOD CODE: BPHBC13842
A: 47
C: 31,5
L: 36
